Merida Big Seven 100 M(17) Kit Frm
Big Seven 100 M(17) Kit Frm: Agile 27.5" Hardtail Performance
Introducing the Big Seven 100 M(17) Kit Frm, an aluminum 27.5" hardtail designed for enhanced comfort and control, thanks to its 100 mm air suspension fork. This bike features a double chainset providing a broad, off-road-ready gear range and hydraulic disc brakes for dependable stopping power in all weather conditions. With its 100 mm air suspension fork and easy-to-accelerate, nimble 27.5" wheels, the BIG.SEVEN 100 enables efficient ground coverage with precise control. The slightly more streamlined double chainring setup offers an extensive range of gears, ideal for extended off-road adventures and quick urban commutes. Furthermore, its slightly more upright riding position reduces strain on the lower back and improves visibility of the path ahead.
This model serves as an excellent alternative to our BIG.NINE 29er hardtails for cyclists who prefer the agile feel of smaller 27.5" wheels. The latest generation of aluminum frames in our BIG.SEVEN TFS and SPEED mountain bikes features slimmer tube shapes for a fresh aesthetic and a more relaxed geometry. A shorter top tube and higher head tube contribute to a more upright riding posture and enhanced trail visibility. Much like our 29er-wheeled BIG.NINE series, our classic BIG.SEVEN hardtails are foundational to our product line. They showcase the immense expertise and knowledge we've gathered over nearly half a century of bike production and manufacturing. These bikes embody the perfect blend of modern frame technology, meticulous attention to detail, and quality craftsmanship "Made in Taiwan."
- Double butted aluminium frame with 27.5" wheels
- Less aggressive and more upright geometry for maximum control and comfort
- Suntour 100 mm travel air suspension fork with lockout
- Shimano 9-speed drivetrain with double chainring setup
- Hydraulic disc brakes
- Internal cable routing
SPECIFICATIONS
- 2 piston
- material: aluminium
- 27.5x2.25" max. wheelsize
- 135x9mm axle standard
- BSA bottom bracket standard
- Air
- 100mm suspension travel
- Lockout
- 42mm fork offset
- 180 mm
- 160 mm
- 36-22 teeth
- 170 mm-S, 175 mm-M up
- 100x9mm width front hub
- 32 spoke holes
- Centerlock
- 135x9mm width rear hub
- 32 spoke holes
- Centerlock
- 20mm inner width
- material: aluminium
- 11-36 teeth
- 9 speed
- 27.5x2.2"
- wire
- 27.5x2.2"
- wire
- material: aluminium
- 31.8mm diameter
- 7° stem angle
- 50 mm
- material: aluminium
- 720mm width
- 10mm rise
- material: aluminium
- 30.9mm diameter
- 0mm setback
- V-mount
Frame Size | XS | S | M | L |
Tyre Sizes | 27.5" | 27.5" | 27.5" | 27.5" |
ST seat tube [mm] | 340 | 380 | 440 | 480 |
TT top tube [mm] | 550 | 570 | 590 | 610 |
CS chain stay length [mm] | 430 | 430 | 430 | 430 |
HTA head tube angle [°] | 69 | 69 | 69 | 69 |
STA seat tube angle [°] | 73 | 73 | 73 | 73 |
BD bottom bracket drop [mm] | 30 | 30 | 30 | 30 |
HT head tube [mm] | 100 | 115 | 130 | 145 |
FL fork length [mm] | 487 | 487 | 487 | 487 |
R reach [mm] | 378 | 394 | 409 | 425 |
S stack [mm] | 563 | 577 | 591 | 605 |
WB wheel base [mm] | 1056 | 1078 | 1099 | 1120 |
SH stand over height [mm] | 649 | 689 | 740 | 778 |
