Polygon Siskiu T7 29r (GREY)
Out of stock
Polygon
The ace: designed to excel on any terrains
Steep climbs with roots, drops, carpets of big rocks, and tight switchback turns. You’ll never get wrong with the adrenaline that rushes in your veins ...
The ace: designed to excel on any terrains
Steep climbs with roots, drops, carpets of big rocks, and tight switchback turns. You’ll never get wrong with the adrenaline that rushes in your veins while riding on those trails. And our Siskiu T, is our ace. A combination of short chainstay, a slacker head tube, and optimized design that inherit the exact DNA of an ace of trails. Get ready to be surprised with the DNA that’s bound with yours.
FEATURES
A perfect riding position with dropper seat post Comes with dropper seat posts that suit your riding style and give you a perfect pedaling position at any time.
Designed for an aggressive ride
Comes with a slack head tube angle and short chainstay, Siskiu T takes you to have an excellent acceleration and the best performance on switchback turns. Along with the reliable hydraulic disc brakes, you are in control.
Easier shift, better experience
There’s more in less. The biggest advantage from a 1x drivetrain is it lets you to focus on your ride, instead of constantly adjusting gears. Now you can have more and better experience on trails.
SPECIFICATION
FRAMESET
Frameset: ALX TRAIL FRAME 140MM TRAVEL (27.5”) / 135MM TRAVEL (29”), TAPER H/T
Fork: ROCKSHOX RECON RL BOOST 15X110MM, 150MM (27.5”) / 140MM (29”) TRAVEL
Rear Shock: Ro DELUXE PLUS SELECT SPECIAL TUNING E2E:210X55MM, HARDWARE:8MMX25MM
Frame Color: MAXIMUM BLUE GREEN - LIME
Decal Color: BLUE GREEN - SHEEN GREEN - BLACK
DRIVETRAIN
Shifter: SHIMANO DEORE SL-M6100-R, 1x12-SPEED TRIGGER
Crank: 12 SPEED 11-51T
Cassette: SHIMANO DEORE CS-M6100 10-51T MICROSPLINE
Rear Derailleur: SHIMANO DEORE RD-M6100-SGS DIRECT ATTACH
BB: SHIMANO 2-PIECE CRANKSET BSA THREADED
Chain: KMC X12 12SPEED
Pedal: -
COCKPIT
Saddle: ENTITY XTEND
Seatpost: TRANZ-X JD-YSP23JL 150mm (S, M) / 170mm TRAVEL (L, XL)
Handlebar: ENTITY XPERT, ALLOY W:780MM R:20MM BB:35MM
Handlestem: ENTITY XPERT, ALLOY E:35MM R:7DEG BB:35MM
Headset: ZERO STACK (ZS) SEALED BEARING FOR TAPER HEAD TUBE, ZS 44/28.6 | ZS 56/40
WHEEL & TIRE
Wheel Set: ENTITY XL2 DISC
Wheel Size: 27.5" / 29"
Tire: PERFORMANCE TIRE, 27.5"X2.60"/29”X2.60"
Rim: 584 / 622-35 32H FOR TYRE 584 / 622-54/76 TUBELESS READY
BRAKE
Brake Lever: TEKTRO LEVER
Brake Caliper: TEKTRO HD-M735 HYDRAULIC DISC BRAKES
Rotor: SHIMANO SM-RT54 180mm CENTER-LOCK
GEOMETRY & SIZE CHART
| S (27.5″) | M (27.5″) | M (29″) | L (29″) | XL (29″) | |
|---|---|---|---|---|---|
| Height (cm) | 155-165 | 165-175 | 165-175 | 175-185 | 185-195 |
| Seat Tube Length (A) | 385 | 400 | 400 | 415 | 430 |
| Seat Tube Angle (B) | 71 | 71 | 70.5 | 70.5 | 70.5 |
| Effective Seat Tube Angle (C) | 76.5 | 76.5 | 76.5 | 76.5 | 76.5 |
| Head Tube Length (D) | 105 | 120 | 90 | 105 | 120 |
| Head Tube Angle (E) | 65 | 65 | 65.5 | 65.5 | 65.5 |
| Effective Top Tube (F) | 582.5 | 605.7 | 605.9 | 629.1 | 652.4 |
| Bb Height (G) | 335 | 334 | 334 | 335 | 335 |
| Bb Offset (H) | 20 | 20 | 39 | 39 | 39 |
| Chainstay Length (I) | 425 | 425 | 429 | 430 | 430 |
| Wheelbase (J) | 1172.8 | 1199.1 | 1193.5 | 1219.7 | 1245.9 |
| Frame Reach (K) | 440 | 460 | 460 | 480 | 500 |
| Frame Stack (L) | 593.5 | 607.1 | 607.6 | 621.2 | 634.9 |
| Standover Height (M) | 666.6 | 672.5 | 676.6 | 686.2 | 695.9 |
