Polygon Strattos S5 -(White)
In stock
Polygon
YOUR GATEWAY TO A WHOLE NEW DIMENSION OF FUN
ASTONISHINGLY RESPONSIVE, SMOOTH, AND FAST
The exhilaration as you step on the pedal, feel the wind rush around you, and sense your heartbeat rising. The all-new Strattos defines a new way of experiencing the road. Designed with tranquil, hours-long rides in mind, Strattos improves upon the comfort of riding, without compromising on performance. Whether for a scenic ride with friends or a high-adrenaline race around the block; Strattos is the best friend that would always be ready to ride with you.
Specifications
-
Frameset
ALX ALL-ROUND, HUB SPACING: QRx130mm
-
Fork
ACX ALL-ROUND, TAPER 1-1/8" TO 1-1/2"
-
Shifter
SHIMANO 105 ST-R7000, 2x11-SPEED
-
Crank
SHIMANO 105 FC-R7000 50/34T, 170mm (XS, S, M) / 172.5mm (L, XL)
-
Cassette
SHIMANO 105 CS-R7000 11-30T
-
Rear Derailleur
SHIMANO 105 RD-R7000-SS DIRECT ATTACH
-
BB
SHIMANO BB-RS500
-
Chain
KMC X11-1
-
Pedal
ALLOY CAGE & BODY W/ REFLECTOR
-
Saddle
ENTITY, STEEL ø 7mm
-
Seatpost
ENTITY SPORT ALLOY, DXL: 27.2 x 350mm
-
Handlebar
ENTITY SPORT ALLOY, W: 400mm (XS, S, M) / 420mm (L, XL), BB: 31.8mm, R/D: 124mm, B/R: 80mm
-
Handlestem
ENTITY SPORT ALLOY, EXT: 90mm (XS, S) / 100mm (M, L) / 110mm (XL), BB: 31.8mm, R/D: 7degree
-
Headset
ZERO STACK (ZS) SEALED BEARING FOR TAPER HEAD TUBE, IS 42/28.6 | IS 52/40
-
Wheel Set
ENTITY XL3
-
Wheel Size
700C
-
Tire
PERFORMANCE TIRE 700x28C
-
Brake Lever
SHIMANO 105 ST-R7000
-
Brake Caliper
SHIMANO 105 BR-R7000
-
Weight
N/A
-
Color
White
-
Country of Origin
Indonesia
Size Chart
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Height (cm) | 154-164 | 162-170 | 168-176 | 174-181 | 180-187 |
| Seat Tube Length (A) | 450 | 470 | 500 | 520 | 550 |
| Seat Tube Angle (B) | 75 | 74.5 | 74 | 73.5 | 73 |
| Effective Seat Tube Angle (C) | 75 | 74.5 | 74 | 73.5 | 73 |
| Head Tube Length (D) | 90 | 105 | 130 | 155 | 185 |
| Head Tube Angle (E) | 72 | 72.5 | 73 | 73 | 73 |
| Effective Top Tube (F) | 515 | 525 | 540 | 555 | 570 |
| Bb Height (G) | 272 | 272 | 274.5 | 274.5 | 277 |
| Bb Offset (H) | 72.5 | 72.5 | 70 | 70 | 67.5 |
| Chainstay Length (I) | 415 | 415 | 415 | 415 | 415 |
| Wheelbase (J) | 975.54 | 977.32 | 984.83 | 995.01 | 1005.89 |
| Frame Reach (K) | 382.5 | 383.5 | 387.1 | 390 | 391.6 |
| Frame Stack (L) | 494.4 | 510.3 | 533.3 | 557.2 | 583.4 |
| Standover Height (M) | 696.7 | 715.7 | 746.5 | 767.1 | 521.2 |
