Alloy frame
RST Neon T fork
SHIMANO Tourney components
Geometry
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Min. figure |
150 | 165 | 175 | 185 |
| Max. figure |
168 | 178 | 188 | 200 |
| S/T c-t |
406 | 457 | 508 | 559 |
| S/T c-c |
0 | 0 | 0 | 0 |
| T/T h |
560 | 580 | 600 | 620 |
| T/T a |
545 | 559 | 575 | 595 |
| H/T |
110 | 130 | 150 | 160 |
| C/S |
450 | 450 | 450 | 450 |
| W/B |
1053 | 1079 | 1099 | 1120 |
| S/T ang. |
73 | 73 | 73 | 73 |
| H/T ang. |
71 | 71 | 71 | 71 |
| F/L |
490 | 490 | 490 | 490 |
| B/B drop |
60 | 60 | 60 | 60 |
| B/B width |
68 | 68 | 68 | 68 |
| Reach |
0 | 0 | 0 | 0 |
| Stack |
0 | 0 | 0 | 0 |
| F/R |
51 | 51 | 51 | 51 |
| Handlebars |
0 | 0 | 0 | 0 |
| Stem |
0 | 0 | 0 | 0 |
| Cranks |
0 | 0 | 0 | 0 |
- S/T c-t - seat tube (center-top), length of the seat tube from the middle of BB parts to its peak
- S/T c-c - seat tube (center-center), length of the seat tube from the middle of BB parts to an axle of the upper tube
- T/T h - top tube horizontal, horizontal lenght of the upper tube
- T/T a - top tube actual, real lenght of the upper tube
- H/T - head tube, head tube lenght
- C/S - chain stay, chain brace lenght
- W/B - wheel base, wheelbase (front and rear axle lenght)
- S/T ang. - seat tube angel, angle between the seat tube axis and an imaginary line connecting the axes of the front and rear wheel
- H/T ang. - head tube angel, angle between the head tube axis and an imaginary line connecting axes of the front and rear wheels
- F/L - fork length, fork length from the head parts bottom to the middle of the front wheel
- B/B drop - bottom bracked drop, lenght between an imaginary line connecting wheels centers and BB parts, measured from BB parts
- F/R - fork rake, distances between the head tube axis and fork axis measured at center of the front wheel, so-called. off set
