Magicshine EVO 1300 Underneath Mounted Front Light

Magicshine EVO 1300 Underneath Mounted Front Light: Your Upside-Down Advantage for Cycling Missions

The EVO 1300 delivers exceptional performance with a potent 1300-lumen output and an impressive 150-meter beam distance, allowing you to confidently navigate diverse environments, from bustling city streets to winding country paths and even demanding off-road terrain.

What sets the EVO 1300 apart is its distinctive optical lens system. This meticulously engineered lens is designed to project a low beam with a precise cutoff line. This intelligent light distribution keeps the beam focused on the road ahead while preventing any upward or outward scatter that could potentially blind oncoming road users. This innovation significantly enhances safety for all road participants, making it particularly well-suited for urban riding or commuting in high-traffic zones. For situations demanding more expansive light, such as faster riding or tackling off-road trails, a simple button press activates the high beam. The EVO 1300's high beam extends beyond the standard cutoff, providing crucial extra illumination to detect obstacles early and navigate curves effectively.

The EVO 1300 light also distinguishes itself with an innovative mounting system that ingeniously maximizes handlebar real estate. The light is positioned discreetly underneath, leaving the top of the handlebar free for your bike computer. This lightweight out-front mount incorporates a user-friendly Garmin quick-release design, making the installation and removal of the light incredibly fast and simple, achievable in mere seconds.

Achieving perfect illumination is effortless with the Magicshine App. This intuitive tool grants you the power to meticulously customize your lighting preferences, integrate new modes, and precisely adjust brightness levels to perfectly match your specific requirements. Furthermore, you can seamlessly switch between low and high beams using the convenient wireless remote control. This eliminates the need to remove your hands from the handlebars, allowing you to maintain focus and ride with complete ease, day and night.

Powered by a reliable 3200mAh battery, the EVO 1300 offers a dependable, day-long runtime. When a recharge is needed, the integrated USB-C port provides convenient power-ups. An IPX6 waterproof rating ensures the light performs flawlessly in all riding conditions, continuing to illuminate your path even through heavy rain.

FEATURES

• High-power LED provides a maximum output of 1300 lumens
• Unique combination of close-range low beam and far-reaching high beam
• Cut-off low beam, glare-free for oncoming road users
• Customize lighting settings for different cycling scenarios via Magicshine App.
• Lightweight out-front mount installs the light underneath most handlebars
• Wireless remote control, straight forward to activate max.output
• Dual-button brightness control, jump to high beam with a single push
• Powered by 2*18500 battery cells with a total capacity of 3200mAh
• USB-C rechargeable
• One-piece seamless aluminum housing for efficient heat dissipation and optimum performance
• Memory function saves the last selected mode
• Lock function to avoid mis-operation
• IPX6 waterproof rating, heavy rain resistant
• 1 year Warranty

OPERATING FEATURES

Switch - A switch on the light unit and a wireless remote control all modes and brightness.

On/Off - Press and hold the button to turn the light on/off. The default output is the last mode when turned off.

Adjust Brightness - When the light is on, click the button to change brightness level. The output brightness of the low beam will cycle through Low→Medium→High→Low...
• When in a high beam, click the button to change the brightness level in a customized setting.
*There is only one brightness level of the high beam by default, and this function is only available when you have customized multiple brightness levels of the high beam via Magicshine App.

Mode Selection- When the light is on, double click the button to change between low beam and high beam.
*There is only one brightness level of the high beam by default, and this function is only available when you have customized multiple brightness levels of the high beam via Magicshine App.

Full Output Mode - When the light is on, click the button to change to the full output mode of the high beam (1300LM).

Lock/Unlock - When the light is off, press and hold the button for 3 seconds to enter lockout mode. To unlock the light, you can press and hold the button again for 3 seconds or charge the light.

Battery Indicator - When the light is off, click the power button to display the remaining battery level for 3 seconds.
Green: 100%-21%, Red: 20%-11%, Flashing Red: 10%-1%

WIRELESS REMOTE CONTROL

• Pairing: Turn on the light, press and hold the "○""□" buttons on the remote for about 10 seconds until the indicator alternately flashes blue to enter pairing mode. Then, put the remote close to the light button until the indicators on the remote and light unit are constantly blue for 2 seconds, confirming a successful pairing.
• On/Off: Press and hold the "○"/"□" button for 1 second
• Adjust brightness: Click the "○" button
• Change mode: Double click the "○" button
• Flash mode: Double click the "□" button
• Full output mode (1300LM): Click the "□" button to go into full output mode and click the "○"/"□" button to return to the previous mode
• The remote control will enter sleep mode if the light is turned off for more than 48 hours without any operation. Click the light's button to activate it or long-press the light's button to turn it on, and the remote control can work normally

CONNECT WITH APP

• iOS users search for "Magicshine" in the "APP Store," and Android users search for "Magicshine" in "Google Play" to download the App.
• Turn on the Bluetooth of your smartphone and open the APP, click "Add New Devices" and find "M2-B0". Click "Add", then click "Connect the device".

APP SETTINGS

• Click "Add" at the bottom to enter the "Device Settings" interface
• Click "Mode 1" or "Mode 2", you can customize "Always On", "SOS", "Blinking", and "Warning" as well as their corresponding brightness
• Up to 20 customized modes are supported.
• When you delete all customized modes in the App, the light will return to the factory default mode
