Marin Nicasio+ (Green)
In stock
Marin
ADVENTURE ROAD AND OFF-ROAD RIDING
LONG DISTANCE COMMUTING
ENDURANCE AND ALL-WEATHER PAVEMENT
The Marin Nicasio+ is our Nic’ with a modern twist, switching in big-volume 47mm rubber, 650b wheels and a sleek and simple 1X drivetrain. We also specced a microSHIFT 1x9 drivetrain, powerful Tektro mechanical discs and plenty of Marin components. Those WTB Horizon 650Bx47mm tires not only provide a cloud-like ride, but also look super dreamy with tan sidewalls.
Key upgrades over the Nicasio:
- 650x47mm wheelset w/WTB Horizon tires
- microSHIFT wide range 1x9 drivetrain
SPECIFICATIONS
-
FRAME
Series 1 Double Butted CrMo Beyond Road, 650B Wheels, Beyond Road Geometry, Fender and Rack Mounts, Disc Mount
-
FORK
CrMo, Fender and Rack Eyelets, IS Disc Mount
-
RIMS
Marin Aluminum Double Wall, 25mm Inner, Disc Specific
-
HUB, REAR
Forged Aluminum Alloy, Disc, 32H
-
HUB, FRONT
Forged Aluminum Alloy, Disc, 32H
-
SPOKE, NIPPLES
14g Black Stainless Steel
-
TIRES
WTB Horizon, 650Bx47mm
-
DERAILLEUR, REAR
microSHIFT Advent, 1x9 w/ Clutch Mech
-
DERAILLEUR, FRONT
N/A
-
SHIFT LEVER
microSHIFT Advent, 1x9 Specific
-
CRANKSET
FSA Vero Pro, Narrow Wide, 42T
-
BOTTOM BRACKET
Sealed Cartridge Bearings, Square Taper
-
CHAIN
KMC X9
-
CASSETTE
SunRace 9-Speed, 11-46T
-
BRAKE, FRONT
Tektro Road Mechanical Disc, 160mm Rotor
-
BRAKE, REAR
Tektro Road Mechanical Disc, 160mm Rotor
-
BRAKE LEVERS
microSHIFT Advent
-
HANDLEBAR
Marin Butted Alloy, Compact 12º Flared Drop
-
STEM
Marin 3D Forged Alloy
-
GRIPS
Marin Comfort Tape
-
HEADSET
FSA No.8D, Sealed Cartridge Bearings
-
SEATPOST
Marin Alloy, 27.2mm
-
SADDLE
Marin Beyond Road Concept
-
PEDALS
Commute Platform
Specifications, pricing, and availability are subject to change without notice.
GEOMETRY
| 50 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|
| STACK | 541.26 | 555.4 | 574.52 | 590.64 | 609.72 | 619.25 |
| REACH | 359.8 | 360.48 | 378.42 | 384.42 | 398.59 | 404.75 |
| HEADTUBE ANGLE | 70.5° | 70.5° | 72° | 72.5° | 72.5° | 72.5° |
| HEADTUBE LENGTH | 130 | 145 | 155 | 170 | 190 | 200 |
| SEATTUBE ANGLE | 74° | 73.5° | 73.5° | 73° | 73° | 72.5° |
| SEATTUBE LENGTH | 470 | 490 | 510 | 530 | 550 | 570 |
| TOPTUBE EFFECTIVE | 515 | 525 | 545 | 565 | 585 | 600 |
| BB HEIGHT | 269 | 269 | 269 | 269 | 269 | 269 |
| BB DROP | 72 | 72 | 72 | 72 | 72 | 72 |
| CHAINSTAY | 420 | 420 | 420 | 420 | 420 | 420 |
| WHEELBASE | 1000.22 | 993.92 | 999.2 | 1008.92 | 1029.1 | 1038.26 |
| STANDOVER HEIGHT | 721.09 | 741.53 | 758.79 | 777.05 | 796.2 | 812.46 |
| FORK OFFSET | 57 | 57 | 45 | 45 | 45 | 45 |
| SEATPOST DIAMETER | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
| HANDLEBAR WIDTH | 400 | 400 | 420 | 420 | 440 | 440 |
| STEM LENGTH | 75 | 75 | 90 | 90 | 90 | 90 |
| CRANK LENGTH | 170 | 170 | 175 | 175 | 175 | 175 |
All lengths in millimeters
TECHNOLOGY
BEYOND ROAD GEOMETRY
Beyond Road Geometry offers a blend of endurance road handling with enhanced stability for off pavement use.
STEEL FRAME CONSTRUCTION
The Nicasio uses a Series 2 or Series 1 butted 4130 CrMo frame with disc brakes, full fender and rack mounts, and two to three bottle bosses.
DISC BRAKES
Disc brakes provide smooth, controlled stopping in all conditions with minimal maintenance.
TIRE CLEARANCE
The Nicasio frame and fork has clearance for up to 700C x 35mm or 650B x 47mm tires.
